ZCT-1414
| ZCT-1414 2-Way Pallet Shuttle Optimized Shuttle Solution for 1400 × 1400 mm Pallets Overview The ZCT-1414 2-Way Pallet Shuttle is specifically designed for oversized pallets, providing reliable and efficient material handling in high-density warehouses. Its sturdy construction and precise operation ensure smooth movement for large and heavy loads, making it perfect for food, beverage, electronics, and general manufacturing warehouses. The shuttle navigates along straight rails within deep-lane racking, maximizing storage density and throughput. Model Overview Parameter Value Model ZCT-1414 Pallet Size (W × D) 1400 × 1400 mm Movement 2-Way (Forward & Backward) Load Capacity 1200 / 1500 kg Lifting Height Max. 50 mm Power Supply Battery Key Features High-precision bi-directional shuttle movement for large pallets Mechanical screw lifting mechanism ensures stability and accuracy DC servo drive system for smooth acceleration and deceleration Wireless remote control (433 MHz) for flexible operation Long-lasting LiFePO4 battery with fast recharge capability Suitable for standard and oversized pallet storage applications typical Applications Warehouses storing large pallets (1400 × 1400 mm) Food & beverage bulk storage Electronics component warehouses High-density automated storage systems Cold storage and climate-controlled warehouses Rail & Deceleration Options Option Rail Size Deceleration Method A 50 × 148 mm Plate deceleration Option A – 50 × 148 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1206 B – Wheel Bottom to Surface: 118 C – Shuttle Height: 187 D – Wheel Diameter: 100 E – Guide Wheel Spacing: 1108 F – Body Width: 1065 G – Front & Rear Wheel Distance: 1120 H – Pallet Deceleration Sensor Distance: 1360 I – Lifting Platform Depth: 1400 J – Shuttle Depth: 1460 Rail Spacing: 1212 Recommended for: Oversized pallets requiring careful deceleration and stable operation in deep-lane racking systems. General Specifications Item Specification Speed (Empty) >60 m/min Speed (Loaded) 36–54 m/min Battery Type LiFePO4 Battery Voltage 24 V Battery Capacity 60 Ah Charging Time ~3 hours Operating Time ~8 hours Motor Type DC Servo Remote Range 100 m Frequency 433 MHz System Integration The ZCT-1414 2-Way Pallet Shuttle is ideal for large-scale, oversized pallet handling systems and can be seamlessly integrated into complex warehouse operations: Large-pallet racking and deep-lane storage systems Forklift-assisted loading and unloading processes Conveyor integration for continuous material flow Autonomous Mobile Robots (AMRs) for flexible warehousing solutions Warehouse Management Systems (WMS) for inventory tracking and operational control Semi-automated and fully automated warehouses This model is tailored to support high-throughput environments, allowing safe and efficient handling of very large pallets while optimizing storage space utilization. Call to Action Looking for a 2-Way Pallet Shuttle designed for 1400 × 1400 mm oversized pallets? Contact us for: Expert technical consultation Fast quotation 👉 Get a Quote / Contact Us |
