ZCT-1311
| ZCT-1311 2-Way Pallet Shuttle Advanced Shuttle Solution for 1300 × 1100 mm Pallets Overview The ZCT-1311 2-Way Pallet Shuttle is built to optimize handling of 1300 × 1100 mm pallets in high-density warehouse systems. Designed for industries such as food, beverage, electronics, and general manufacturing, it operates smoothly along straight rails within deep-lane racking, maximizing storage capacity while reducing manual labor and operational costs. Modell Overview Parameter Value Model ZCT-1311 Pallet Size (W × D) 1300 × 1100 mm Movement 2-Way (Forward & Backward) Load Capacity 1200 / 1500 kg Lifting Height Max. 50 mm Power Supply Battery Key Features Precise bi-directional shuttle operation along rails Mechanical screw lifting mechanism for stable vertical movement High-performance DC servo drive system Wireless remote control (433 MHz) for flexible management Efficient LiFePO4 battery with rapid charging for extended operation Designed for cold storage and standard warehouse applications Typical Applications Large-pallet warehouses (1300 × 1100 mm) Food & beverage storage Electronics manufacturing and assembly storage High-density storage systems requiring automated material handling Cold storage facilities and climate-controlled warehouses Rail & Deceleration Options Option Rail Size Deceleration Method A 50 × 148 mm Dual-hole deceleration B 70 × 163 mm Plate deceleration C 70 × 130 mm Plate deceleration D 50 × 148 mm Plate deceleration Option A – 50 × 148 mm Rail (Dual-hole Deceleration)  Parameter Value (mm) A – Shuttle Width: 1108 B – Shuttle Depth: 1300 C – Shuttle Height: 191 D – Wheel Bottom to Surface: 118 E – Lifting Platform Width: 1070 F – Lifting Platform Depth: 1120 G – Body Width: 980 H – Pallet Sensor Distance: 1060 Rail Spacing: 1112 Recommended for: Heavy-load applications with high stability and precise positioning. Option B – 70 × 163 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1079 B – Shuttle Depth: 1160 C – Shuttle Height: 192.5 D – Wheel Bottom to Surface: 147.5 E – Lifting Platform Width: 1040 F – Lifting Platform Depth: 1110 G – Body Width: 910 H – Pallet Sensor Distance: 1060 Rail Spacing: 1083 Recommended for: Applications requiring smoother deceleration and improved shuttle positioning accuracy. Option C – 70 × 130 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1174 B – Shuttle Depth: 1120 C – Shuttle Height: 175 D – Wheel Bottom to Surface: 120 E – Lifting Platform Width: 1120 F – Lifting Platform Depth: 1082 G – Body Width: 1020 H – Pallet Sensor Distance: 1060 Rail Spacing: 1180 Recommended for: Compact warehouse layouts or projects requiring specialized shuttle dimensions. Option D – 50 × 148 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1106 B – Wheel Bottom to Surface: 118 C – Shuttle Height: 186 D – Wheel Diameter: 100 E – Guide Wheel Spacing: 1008 F – Body Width: 965 G – Front & Rear Wheel Distance: 820 H – Pallet Deceleration Sensor Distance: 1060 I - Lifting Platform Depth: 1100 J – Shuttle Depth: 1160 Rail Spacing: 1112 Recommended for: Standard warehouse configurations requiring flexible shuttle setups. General Specifications Item Specification Speed (Empty) >60 m/min Speed (Loaded) 36–54 m/min Battery Type LiFePO4 Battery Voltage 24 V Battery Capacity 60 Ah Charging Time ~3 hours Operating Time ~8 hours Motor Type DC Servo Remote Range 100 m Frequency 433 MHz System Integration The ZCT-1311 2-Way Pallet Shuttle can be integrated into modern warehouse operations, providing reliable automation for large-pallet handling. It supports: Automated pallet racking systems for optimized storage density Forklift-assisted material handling workflows Conveyor systems connecting multiple processing stages Autonomous Mobile Robots (AMRs) for enhanced warehouse mobility Warehouse Management Systems (WMS) for precise inventory control Semi-automated and fully automated warehouse configurations This model is ideal for manufacturers and distributors who require efficient handling of oversized pallets while maintaining high safety and operational efficiency. Call to Action Looking for a reliable 2-Way Pallet Shuttle for 1300 × 1100 mm pallets? Contact us for: Expert technical consultation Rapid quotation 👉 Get a Quote / Contact Us |
