ZCT-1212
| ZCT-1212 2-Way Pallet Shuttle Optimized High-Density Shuttle Solution for 1200 × 1200 mm Pallets Overview The ZCT-1212 2-Way Pallet Shuttle is engineered for reliable handling of 1200 × 1200 mm pallets within high-density warehouse racks. It provides efficient, automated material flow along straight rails and is ideal for industries such as food, beverage, electronics, and general manufacturing. This shuttle minimizes manual labor and maximizes storage density for large-scale operations. Model Overview Parameter Value Model ZCT-1212 Pallet Size (W × D) 1200 × 1200 mm Movement 2-Way (Forward & Backward) Load Capacity 1200 / 1500 kg Lifting Height Max. 50 mm Power Supply Battery Key Features Bi-directional shuttle movement with precise positioning Robust mechanical screw lifting mechanism DC servo drive system ensures smooth acceleration and reliable operation Wireless remote control (433 MHz) for flexible operation Long-lasting LiFePO4 battery with rapid charging capability Suitable for high-density storage and cold storage applications Typical Applications Standard 1200 × 1200 mm pallet warehouses Food & beverage storage facilities Electronics and component manufacturing storage Cold storage and temperature-controlled warehouses High-density pallet racking systems requiring automated shuttle solutions Rail & Deceleration Options Option Rail Size Deceleration Method A 50 × 148 mm Dual-hole deceleration B 70 × 163 mm Plate deceleration C 50 × 148 mm Plate deceleration Option A – 50 × 148 mm Rail (Dual-hole Deceleration)  Parameter Value (mm) A – Shuttle Width: 1008 B – Shuttle Depth: 1400 C – Shuttle Height: 191 D – Wheel Bottom to Surface: 118 E – Lifting Platform Width: 970 F – Lifting Platform Depth: 1220 G – Body Width: 880 H – Pallet Sensor Distance: 1160 Rail Spacing: 1012 Recommended for: Heavy-load applications with stable operation and high reliability. Option B – 70 × 163 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 979 B – Shuttle Depth: 1260 C – Shuttle Height: 192.5 D – Wheel Bottom to Surface: 147.5 E – Lifting Platform Width: 940 F – Lifting Platform Depth: 1210 G – Body Width: 810 H – Pallet Sensor Distance: 1160 Rail Spacing: 983 Recommended for: Applications that require smoother deceleration and improved positioning accuracy. Option C – 50 × 148 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1006 B – Wheel Bottom to Surface: 118 C – Shuttle Height: 186 D – Wheel Diameter: 100 E – Guide Wheel Spacing: 908 F – Body Width: 865 G – Front & Rear Wheel Distance: 920 H – Pallet Deceleration Sensor Distance: 1160 I – Lifting Platform Depth: 1200 J – Shuttle Depth: 1260 Rail Spacing: 1012 Recommended for: Flexible warehouse layouts and operations requiring compact shuttle configurations. General Specifications Item Specification Speed (Empty) >60 m/min Speed (Loaded) 36–54 m/min Battery Type LiFePO4 Battery Voltage 24 V Battery Capacity 60 Ah Charging Time ~3 hours Operating Time ~8 hours Motor Type DC Servo Remote Range 100 m Frequency 433 MHz System Integration The ZCT-1212 2-Way Pallet Shuttle is designed for easy integration into a wide range of material handling systems. Its flexible communication and compact footprint make it ideal for: Fully automated racking systems for optimized warehouse density Integration with forklifts and manual pallet operations Conveyor systems to link with upstream and downstream processes Autonomous Mobile Robots (AMRs) to enhance warehouse mobility Warehouse Management Systems (WMS) for precise inventory tracking Hybrid semi-automated or fully automated warehouse setups This shuttle enables improved throughput, reduces operational labor, and ensures safe and efficient handling of standard 1200 × 1200 mm pallets. Call to Action Looking for a high-performance 2-Way Pallet Shuttle for 1200 × 1200 mm pallets? Contact us for: Technical consultation Fast quotation 👉 Get a Quote / Contact Us |
