ZCT-1313
| ZCT-1313 2-Way Pallet Shuttle Efficient Shuttle Solution for 1300 × 1300 mm Pallets Overview The ZCT-1313 2-Way Pallet Shuttle is engineered for high-capacity handling of 1300 × 1300 mm pallets in demanding warehouse environments. Its robust design and precise operation make it ideal for industries such as food, beverage, electronics, and general manufacturing. Operating along straight rails in deep-lane racking, it maximizes storage density while ensuring safe and reliable pallet transport. Model Overview Parameter Value Model ZCT-1313 Pallet Size (W × D) 1300 × 1300 mm Movement 2-Way (Forward & Backward) Load Capacity 1200 / 1500 kg Lifting Height Max. 50 mm Power Supply Battery Key Features High-precision bi-directional shuttle operation Mechanical screw lifting for stable vertical movement DC servo drive system for smooth and consistent speed Wireless remote control (433 MHz) for flexible operation Long-life LiFePO4 battery with rapid charging capability Designed for both standard and cold storage warehouse applications Typical Applications Large square-pallet warehouses (1300 × 1300 mm) Food & beverage storage environments Electronics manufacturing storage High-density automated storage systems Cold storage and climate-controlled warehouse operations Rail & Deceleration Options Option Rail Size Deceleration Method A 50 × 148 mm Dual-hole deceleration B 70 × 163 mm Plate deceleration C 70 × 130 mm Plate deceleration D 50 × 148 mm Plate deceleration Option A – 50 × 148 mm Rail (Dual-hole Deceleration)  Parameter Value (mm) A – Shuttle Width: 1108 B – Shuttle Depth: 1500 C – Shuttle Height: 191 D – Wheel Bottom to Surface: 118 E – Lifting Platform Width: 1070 F – Lifting Platform Depth: 1320 G – Body Width: 980 H – Pallet Sensor Distance: 1260 Rail Spacing: 1112 Recommended for: Heavy-load applications requiring stable and precise pallet positioning. Option B – 70 × 163 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1079 B – Shuttle Depth: 1360 C – Shuttle Height: 192.5 D – Wheel Bottom to Surface: 147.5 E – Lifting Platform Width: 1040 F – Lifting Platform Depth: 1310 G – Body Width: 910 H – Pallet Sensor Distance: 1260 Rail Spacing: 1083 Recommended for: Applications where smoother deceleration and higher shuttle positioning accuracy are desired. Option C – 70 × 130 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1174 B – Shuttle Depth: 1320 C – Shuttle Height: 175 D – Wheel Bottom to Surface: 120 E – Lifting Platform Width: 1120 F – Lifting Platform Depth: 1182 G – Body Width: 1020 H – Pallet Sensor Distance: 1260 Rail Spacing: 1180 Recommended for: Compact layouts or specialized warehouse configurations requiring precise pallet handling. Option D – 50 × 148 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1106 B – Wheel Bottom to Surface: 118 C – Shuttle Height: 187 D – Wheel Diameter: 100 E – Guide Wheel Spacing: 1008 F – Body Width: 965 G – Front & Rear Wheel Distance: 1020 H – Pallet Deceleration Sensor Distance: 1260 I – Lifting Platform Depth: 1300 J – Shuttle Depth: 1360 Rail Spacing: 1112 Recommended for: Standard warehouse layouts requiring flexible pallet shuttle setups. General Specifications Item Specification Speed (Empty) >60 m/min Speed (Loaded) 36–54 m/min Battery Type LiFePO4 Battery Voltage 24 V Battery Capacity 60 Ah Charging Time ~3 hours Operating Time ~8 hours Motor Type DC Servo Remote Range 100 m Frequency 433 MHz System Integration The ZCT-1313 2-Way Pallet Shuttle is ideal for large-square pallet storage solutions and can be fully integrated into modern warehouse systems: Pallet racking systems optimized for oversized pallets Forklift-assisted material handling workflows Conveyor systems connecting multiple warehouse zones Autonomous Mobile Robots (AMRs) for advanced intralogistics Warehouse Management Systems (WMS) for real-time tracking Semi-automated and fully automated warehouse configurations This model provides enhanced flexibility for oversized pallets, supporting smooth material flow and higher warehouse throughput. Call to Action Looking for a reliable 2-Way Pallet Shuttle for 1300 × 1300 mm square pallets? Contact us for: Expert technical consultation Quick quotation 👉 Get a Quote / Contact Us |
