ZCT-1210
| ZCT-1210 2-Way Pallet Shuttle Optimized Shuttle Solution for 1200 × 1000 mm Pallets Overview The ZCT-1210 2-Way Pallet Shuttle is specifically designed for high-density warehouse storage systems handling 1200 × 1000 mm pallets. It operates along straight rails inside deep-lane racking, offering a cost-effective and reliable solution for industries such as food & beverage, electronics manufacturing, and general warehousing. Its compact design allows for efficient storage utilization and fast material flow. Model Overview Parameter Value Model ZCT-1210 Pallet Size (W × D) 1200 × 1000 mm Movement 2-Way (Forward & Backward) Load Capacity 1200 / 1500 kg Lifting Height Max. 50 mm Power Supply Battery Key Features Stable bi-directional movement along rails High-performance DC servo drive system Mechanical screw lifting mechanism for precise pallet handling Wireless remote control (433 MHz) Fast battery charging and long operational runtime Reliable performance in high-density racking environments Typical Applications Standard 1200 × 1000 mm pallet warehouses Food & beverage cold storage Electronics component storage High-density manufacturing finished goods storage Automated and semi-automated pallet handling systems Rail & Deceleration Options The ZCT-1210 supports multiple rail and deceleration configurations to match different warehouse requirements: Option Rail Size Deceleration Method A 50 × 148 mm Dual-hole deceleration B 70 × 163 mm Plate deceleration C 70 × 130 mm Plate deceleration D 50 × 148 mm Plate deceleration Option A – 50 × 148 mm Rail (Dual-hole Deceleration)  Parameter Value (mm) A – Shuttle Width: 1008 B – Shuttle Depth: 1200 C – Shuttle Height: 191 D – Wheel Bottom to Surface: 118 E – Lifting Platform Width: 970 F – Lifting Platform Depth: 1020 G – Body Width: 880 H – Pallet Sensor Distance: 960 Rail Spacing: 1012 Recommended for: Heavy-load applications requiring precise positioning and stable operation. Option B – 70 × 163 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 979 B – Shuttle Depth: 1060 C – Shuttle Height: 192.5 D – Wheel Bottom to Surface: 147.5 E – Lifting Platform Width: 940 F – Lifting Platform Depth: 1010 G – Body Width: 810 H – Pallet Sensor Distance: 960 Rail Spacing: 983 Recommended for: Applications requiring smoother deceleration and higher positioning accuracy. Option C – 70 × 130 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1074 B – Shuttle Depth: 1020 C – Shuttle Height: 175 D – Wheel Bottom to Surface: 120 E – Lifting Platform Width: 1020 F – Lifting Platform Depth: 982 G – Body Width: 920 H – Pallet Sensor Distance: 960 Rail Spacing: 1080 Recommended for: Compact layouts and space-constrained warehouse environments. Option D – 50 × 148 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width: 1006 B – Wheel Bottom to Surface: 118 C – Shuttle Height: 186 D – Wheel Diameter: 100 E – Guide Wheel Spacing: 908 F – Body Width: 865 G – Front & Rear Wheel Distance: 720 H – Pallet Deceleration Sensor Distance: 960 I – Lifting Platform Depth: 1000 J – Shuttle Depth: 1060 Rail Spacing: 1012 Recommended for: Flexible deceleration configurations in standard rail warehouses. General Specifications Item Specification Speed (Empty) >60 m/min Speed (Loaded) 36–54 m/min Battery Type LiFePO4 Battery Voltage 24 V Battery Capacity 60 Ah Charging Time ~3 hours Operating Time ~8 hours Motor Type DC Servo Remote Range 100 m Frequency 433 MHz System Integration The ZCT-1210 2-Way Pallet Shuttle is designed for seamless integration with modern warehouse systems: Pallet racking systems Forklift operations Conveyor lines Autonomous Mobile Robots (AMRs) Warehouse Management Systems (WMS) Semi-automated and automated storage solutions Its flexible configuration makes it ideal for high-density storage layouts and custom warehouse designs, ensuring smooth and continuous material flow. Call to Action Looking for a high-performance 2-Way Pallet Shuttle for 1200 × 1000 mm pallets? Contact us today for: Technical consultation Fast quotation 👉 Get a Quote / Contact Us |
