ZCT-1208
| ZCT-1208 2-Way Pallet Shuttle Efficient Shuttle Solution for 1200 × 800 mm Pallet Storage Overview The ZCT-1208 2-Way Pallet Shuttle is designed for efficient handling of 1200 × 800 mm pallets in high-density warehouse storage systems. It moves along straight rails inside deep-lane racking, providing a reliable and cost-effective solution for bulk storage applications such as food, beverage, cold storage, and general manufacturing industries. Model Overview Parameter Value Model ZCT-1208 Pallet Size (W × D) 1200 × 800 mm Movement 2-Way (Forward & Backward) Load Capacity 1200 / 1500 kg Lifting Height Max. 50 mm Power Supply Battery Key Features Stable bi-directional movement along rails High-performance DC servo drive system Mechanical screw lifting mechanism Wireless remote control (433 MHz) Long battery life with fast charging Reliable operation for high-density storage Key Features Designed for square pallet storage systems (1100 × 1100 mm) Stable bi-directional movement along rails High-performance DC servo drive system Mechanical screw lifting mechanism Wireless remote control (433 MHz) Long battery life with fast charging Suitable for compact and symmetrical warehouse layouts、 Rail & Deceleration Options The ZCT-1208 supports multiple rail types and deceleration methods: Option Rail Size Deceleration Method A 50 × 148 mm Dual-hole deceleration Custom configurations are available based on project requirements. Option A – 50 × 148 mm Rail (Dual-hole Deceleration)  Parameter Value (mm) A – Shuttle Width 1008 B – Shuttle Depth 1000 C – Shuttle Height 191 D – Wheel to Top Surface 118 E – Lifting Platform Width 970 F – Lifting Platform Depth 820 G – Body Width 880 H – Sensor Distance 780 Rail Spacing 1012 Recommended for: Standard heavy-load applications with stable operation requirements. General Specifications Item Specification Speed (Empty) >60 m/min Speed (Loaded) 36–54 m/min Battery Type LiFePO4 Battery Voltage 24 V Battery Capacity 60 Ah Charging Time ~3 hours Operating Time ~8 hours Motor Type DC Servo Remote Range 100 m Frequency 433 MHz System Integration The ZCT-1208 2-Way Pallet Shuttle can be seamlessly integrated with: Pallet racking systems Forklift operations Conveyor systems Autonomous Mobile Robots (AMRs) Warehouse Management System (WMS) Semi-automated and automated warehouse systems Call to Action Looking for a reliable 2-Way Pallet Shuttle for 1200 × 800 mm pallets? Contact us for: Technical consultation Fast quotation 👉 Get a Quote / Contact Us |
