ZCT-1111
| ZCT-1111 2-Way Pallet Shuttle Optimized Shuttle Solution for 1100 × 1100 mm Square Pallet Storage Overview The ZCT-1111 2-Way Pallet Shuttle is specifically designed for 1100 × 1100 mm square pallets, offering an efficient and flexible solution for high-density warehouse storage systems. Compared with standard rectangular pallet solutions, this model is ideal for industries requiring square pallet handling, such as warehouses for electronic product manufacturing, food and beverage manufacturing, and general manufacturing. It operates along straight rails within deep-lane racking systems, enabling fast, safe, and cost-effective pallet movement. Model Overview Parameter Value Model ZCT-1111 Pallet Size (W × D) 1100 × 1100 mm Movement 2-Way (Forward & Backward) Load Capacity 1200 / 1500 kg Lifting Height Max. 50 mm Power Supply Battery Key Features Designed for square pallet storage systems (1100 × 1100 mm) Stable bi-directional movement along rails High-performance DC servo drive system Mechanical screw lifting mechanism Wireless remote control (433 MHz) Long battery life with fast charging Suitable for compact and symmetrical warehouse layouts Typical Applications Square pallet warehouse systems Electronics manufacturing storage General manufacturing storage Beverage and liquid product storage High-density pallet racking systems with customized pallet sizes Rail & Deceleration Options The ZCT-1111 supports multiple rail configurations to adapt to different warehouse layouts: Option Rail Size Deceleration Method Option A 50 × 148 mm Dual-hole deceleration Option B 70 × 163 mm Plate deceleration Option C 70 × 130 mm Plate deceleration Option D 50 × 148 mm Plate deceleration Option A – 50 × 148 mm Rail (Dual-hole Deceleration)  Parameter Value (mm) A – Shuttle Width 908 B – Shuttle Depth 1300 C – Shuttle Height 191 D – Wheel to Top Surface 118 E – Lifting Platform Width 870 F – Lifting Platform Depth 1120 G – Body Width 780 H – Sensor Distance 1060 Rail Spacing 912 Recommended for: Standard square pallet applications with stable and heavy-load requirements. Option B – 70 × 163 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width 979 B – Shuttle Depth 1160 C – Shuttle Height 192.5 D – Wheel to Top Surface 147.5 E – Lifting Platform Width 940 F – Lifting Platform Depth 1110 G – Body Width 810 H – Sensor Distance 1060 Rail Spacing 983 Recommended for: High-precision positioning and smoother deceleration requirements. Option C – 70 × 130 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width 974 B – Shuttle Depth 1120 C – Shuttle Height 175 D – Wheel to Top Surface 120 E – Lifting Platform Width 920 F – Lifting Platform Depth 1082 G – Body Width 820 H – Sensor Distance 1060 Rail Spacing 980 Recommended for: Low-height warehouse systems and compact installations. Option D – 50 × 148 mm Rail (Plate Deceleration)  Parameter Value (mm) A – Shuttle Width 906 B – Wheel Bottom to Floor 118 C – Shuttle Height 186 D – Wheel Diameter 100 E – Guide Wheel Spacing 808 F – Body Width 765 G – Front & Rear Wheel Distance 820 H – Pallet Sensor Distance 1060 I – Lift Panel Depth 1100 J – Shuttle Depth 1160 Rail Spacing 912 Recommended for: Flexible layouts and customized warehouse configurations. General Specifications Item Specification Speed (Empty) >60 m/min Speed (Loaded) 36–54 m/min Battery Type LiFePO4 Battery Voltage 24 V Battery Capacity 60 Ah Charging Time ~3 hours Operating Time ~8 hours Motor Type DC Servo Remote Range 100 m Frequency 433 MHz System Integration The ZCT-1111 2-Way Pallet Shuttle is optimized for square pallet handling systems and can be seamlessly integrated with: Pallet racking systems Forklift operations Conveyor systems Autonomous Mobile Robots (AMRs) Warehouse Management Systems (WMS) Semi-automated and automated warehouse systems It is particularly suitable for customized warehouse layouts and square pallet storage environments, ensuring efficient material flow and system flexibility. Call to Action Looking for a 2-Way Pallet Shuttle optimized for 1100 × 1100 mm square pallets? Contact us for: Technical consultation Fast quotation 👉 Get a Quote / Contact Us |
