ZCM-400
ZCM-400 1. Product Description ZCM-400 is a compact and flexible mobile robot designed for efficient material handling in modern industrial environments. With a maximum payload of 400 kg, it supports lifting, transportation, and rotation operations, making it suitable for a wide range of logistics and production scenarios. 2. Key Features Advanced Navigation ZCM-400 integrates QR code navigation and Laser SLAM navigation, enabling accurate positioning and stable operation in dynamic and complex environments. Flexible Motion Control The robot adopts a dual-wheel differential drive system, allowing smooth forward, backward, and rotational movements. It is highly maneuverable and suitable for narrow working spaces. Intelligent Power Management Multi-level battery threshold settings Configurable minimum charging level Supports automatic charging during idle time This ensures continuous operation with optimized energy efficiency. Comprehensive Safety Protection Front laser obstacle detection Contact bumper for collision detection Emergency stop button Multiple safety mechanisms ensure safe operation alongside humans. User-Friendly Interaction Simple button control interface Integrated sound and light alarm system Provides clear real-time status indication. Multiple Control Modes Supports: Automatic mode, Manual mode, Remote control Flexible control options for different operational needs. Strong Material Handling Capability Maximum payload: 400 kg Supports lifting, transporting, and rotating functions Customizable load attachments available Adaptable to various application scenarios. Reliable Communication WiFi communication with seamless roaming Optional 5G connectivity Ensures stable and efficient system integration. 3. Applications ZCM-400 is widely used in: E-commerce warehousing 3C electronics manufacturing Tobacco industry Pharmaceutical industry 4. QR Code Layout Requirement Standard spacing: 1000 × 1000 mm Supports flexible and non-uniform QR code layouts 5.Dimensions: L*W*H：780*540*255mm Weight：98Kg Dead Weight ：400Kg Chassis Ground Clearance：25mm Min. swivel diameter：780mm Jacking drive：Electric Jacking height：60mm Lifting speed：2-3S Rated operating speed/no load/full load：1.9/1.5 m/s Acceleration no/full load：0.6/0.3 m/s² Drive mode：Two-wheel differential drive Navigation mode：Laser Slam or QR code Stop position accuracy/angle accuracy：±5mm/±1° Capacity/ rated voltage：16Ah/48V Charge/discharge cycles：Fully charged and discharged 1,500 times Endurance time under rated operating conditions:8H Charging time after complete discharge:≤1.5H
|
